I have been a silent blogger for more than one year. It's actually one year and one month since I have published my last post on 10 January 2011. Things have changed a lot around me and now I'm not even using the Sony Ericsson phone mentioned in my last post!

Two things happened in the last year... on February I got a new phone as a gift from a friend, and on October I got a bike. That's it! Made in India, and called Hero Honda Hunk. It is said that this bike can topped to 112 km/h. For me that's not enough top speed, but this is one of the most stable bikes made in India. Most others waggle and vibrate, but Hunk is very stable at speed.



Due to the extreme excitement of the bike, I'd just forget to mention the phone! It's a Nokia 5230 and not that handy, but enough for my day-to-day activities. Same as most Nokia cameraphones, this one's camera is also not suitable for professional photography. But, its video recording is pretty good.

I really love to ride this Hunk... (despite of its gay name :-) ) it brings lots of excitement every time when it's over 100. Its stability at higher speeds, and stability when cornering, wheelies, stoppies... everything eventually tempted me to have a video collection of it. This is how I become interested in making a HelmetCam. I don't have much of equipments for this, and I've heard somewhere that a professional HelmetCam kit costs over US $200. So why not use my own cameraphone? Here, I'll explain how to get it prepared with a Symbian (Nokia) phone.

The simple setup is to wear your helmet, and then put the cameraphone in, and fasten it. This setup has a problem. Why? Whenever the touchscreen/ keypad hits your nose or somewhere in your face, there's a probability for video recording to interrupt. Or even it can dial emergency while you are on ride!

This is the time for SymDVR to shine. SymDVR is a very handy app which can turn your cameraphone into a DVR with lots of options. The main reason for using this app is, unlike your phone's in-built video recording application this allows you to lock the screen/ keypad while recording. This is a huge advantage as it also keeps the phone's backlight off while recording.


Other advantages include that it can calculate your riding speed using GPS and include as subtitles, landscape recording while keeping the phone in vertical position, etc.

Go to SymDVR homepage, download and install the app on your Nokia phone. Start the application, choose appropriate settings and start video recording. Once you start recording, you will see a Nokia Menu icon on the screen. Tap on it, and SymDVR will continue to record video, running in the background. Now it can be placed even inside your underwear without interrupting the record. :D

Be sure to have a strap for your phone. You can fasten the helmet's strap across phone's strap to make sure it's safe in case if your phone loosens inside the helmet and falls down on to the road. Other than that, the phone will fall onto the road making you distracted, eventually turning you into dead meat. If you don't have a strap, just go and buy. It won't cost much. This is important to avoid accidental distractions.

Image courtesy: fadbus.com

Now, we need to have is a full face helmet. We are going to need a full face helmet because then only it can be held between your face and the helmet.



If you plan to try this out in Sri Lanka, be sure to choose a helmet with a dark tinted visor. Most of the traffic cops are weird jerks, and if they see the cameraphone inside helmet they will remake the story as you were having a phone call while riding. (They just want you to invite them for a bribe). That's Sri Lankan traffic cops. So beware of them.

Firstly hold your phone vertically, and start recording on SymDVR. Then click on Nokia Menu icon to allow SymDVR to run in background, and lock the screen/ keypad. Even if you hold it vertically, SymDVR will record the video clip in landscape mode without having you to flip the phone, and without affecting the clip size.Then, while wearing the helmet, place the cameraphone in the helmet in the way shown in the photo below. It will fit between your face and the helmet.  Finally, cross the straps as described above.

In this setup, cameraphone fits between my face and helmet.

Make sure that your sight is not disturbed by the position of the camera. Letting it cover one eye and seeing the road by the other is prone for accidents. You need your both eyes to get the correct idea of distance to other vehicles on the road. If you still unsure why, read more about depth perception.

If it doesn't fit into your helmet you will have to find a workaround. A good suggestion that I have seen over the Internet is to use Velcro, but the problem is that you will have glue it onto the phone. :-/

Another suggestion of is to use a phone holder such as Nokia CR-119. You will have to remove the cone shaped part which in normal use attaches to a vehicle windshield. Carefully mount the phone into the holder facing the camera out. This arrangement will take more space inside the helmet, and it will fit better if your head is small. :-)

Make sure that camera is facing directly front. Start your ride, bang all over the city. Forget about the phone and enjoy your ride as much as possible.

A great feature that I really love on SymDVR is that it can measure your speed using GPS. This can be different from the actual speed , plus or minus 2 km/h, but with this feature on you don't have to look at the speedometer to get the speed on video. It also helps a lot to avoid distraction. Speed is recorded in a separate subtitle file (srt), and later you can use a video encoding software to merge it with the video file.

Once you are done, take the phone out, and open up SymDVR. Properly stop recording or otherwise you will end up with a corrupted video file. It will take a moment for the video file to be prepared. Once done, you can connect the phone to PC in Mass Storage Mode, and transfer the video file to your PC. It's in \SymDVR\ directory on your phone's memory card. This is by default hidden if you are using Windows on your PC.

After recording if you want to embed subtitles into the video, I recommend using mencoder. If you just want to trim the video file, you can use ffmpeg to get it done without affecting the video quality.

---

I have done some helmetcam videos using this setup. And.... here goes my first performing a stoppie somewhere near the end.........


And another I took at Malabe...


Well,... finally that's it! Thanks for reading.
Enjoy!!

I'm using a Sony Ericsson K770i for more than 1½ years. Since I'm a novice and hobbist photographer my choice was that cameraphone.

Recently, the camera seemed to malfunction. When I open the lens cover, the screen switches between camera viewport and home screen repeatively. Sometimes it looked OK until I capture the scene. This behaviour made things more annoying.

First, I thought this could be a software problem. So I reinstalled the phone's software. But no luck. Then I googled for similar issues and Google took me to this forum discussion. But it also says the same thing.

After examining the camera's unusual behaviour carefully, I realized that there's a low probability of this being a software bug. The problem occurs randomly (not when I do a specific or unusual thing with phone's software). So this should be a hardware problem.

So what could be the problem? Casually I found it.

If you remove the back cover of your K770i phone, you'll see two triangular white tips at the right side of the camera. Now hold the battery with your middle finger and press the upper tip. What you see on screen is the camera viewport. Now try some captures. Will it switch between the home screen and viewport? No.

The problem is actually with the phone's back cover. Hundreds of times I have removed the back cover to change between SIM cards, memory sticks, etc. So it has become loose. It's obvious by looking at this phone, loose back cover means loose lens cover. Nothing wrong with lens cover itself. When you aim the camera, slight movemets of your fingers make the loose cover tighten and loosen, and that tip will press and release repeatively.

So I guess this might be a known issue with K770i. Time spans, back cover loosens.

To temporirily overcome the problem I adjusted the metallic plates in the lens cover. But I advice you not do so yourself and ask for support from a qualified technician.

So this is it. Don't waste time reinstalling any software. Thanks for reading the article.

Recently, I was assigned for a project that required one-way synchronization of data, from MS Access to MySQL. This was required to be fully automated to make the task executed once a day. It has already been implemented by someone else before, using PHP as the programming language, and SOAP protocol as the underlying technology. The implementation had several issues, so I was asked to do it in a different approach.

So, roughly, my plan was to dump the Access database into text, and then upload the dump file to the server, and then import to MySQL. So how to do that?

Microsoft Office Access 2007 provides it's own methods to export table content as CSV, and it's really nice that at the MySQL's end the CSV files can be directly read into the MySQL database. Roughly, my approach looked like the following,

Synchronize necessary tables into MySQL

• Using VBA code, export necessary tables into CSV
• Compress and upload the CSV files, preferably in a single file
• At the MySQL's end, import the data upon the upload completes

Make the whole task fully automated

• Using a MS Access 2007 macro, trigger the VBA code
• Set up Windows task scheduler

Now, let us explore step-by-step... :-)


Synchronization of Necessary Tables into MySQL

I remember that I was doing good with Microsoft Visual Basic 6.0 six-seven years before. Almost forgotten some, I started working with VBA. Basically it's the TransferText method provided by the DoCmd object in MS Access. In brief, following is the code.

I initially wrote this part of code as a Sub in VB, but later I understood that, to be automated with a macro, I have to make this a Function. (Sub does not return a value but a Function does)

Function ExportData ()
 Dim tables (1 To 3) As String
 Dim table As String
 Dim exportpath As String

 exportpath = "C:\temp\"

 table (1) = "tblStudents"
 table (2) = "tblMarks"
 table (3) = "tblSubjects"

 For Each table In Tables
  DoCmd.TransferText acExportDelim, , table, exportpath + table + ".csv"
 Next table

 ExportData = True ' Return True to indicate (in case if necessary) all done without breaking in the middle
End Function

In my work I had to export several tables. However it's that simple. Now, the next task is to upload the exported CSV to the server, through FTP. As far as I know, VBA does not provide any native/in-built methods to handle FTP. The solution is accessing Windows API. I have programmed with Windows API for classic Visual Basic before so I know how hard it can be without a proper documentation. I have found plenty of nice articles over the Internet on how to do it, but as I do not know how it would be working in later Windows releases such as Vista and Seven and how would Internet security software handle that, I decided to use the PHP command line instead of Visual Basic. By installing the XAMPP package in Windows, you can get PHP CLI work. So, the latter part of the above VBA code goes like this,

Dim cmdline
cmdline = "C:\xampp\php\php.exe c:\uploadcsv.php "
For Each table In Tables
 DoCmd.TransferText ()
 cmdline = cmdline + Chr$ (34) + exportpath + table + ".csv" + Chr$ (34) + " "
Next table

Shell cmdline, vbNormalFocus

As you can see, all the exported file paths are passed to a PHP script called uploadcsv.php. Work to be done with VBA code ends here. Now, the next task is to handle the file upload. PHP provides very easy and nice methods to do that.

First, let us examine the command line, the cmdline variable in our VBA code. It will look like the following. Note that Chr$ (34) returns a double quotation mark (ASCII 34).

C:\xampp\php\php.exe c:\uploadcsv.php "C:\temp\tblStudents.csv" "C:\temp\tblMarks .csv" "C:\temp\tblSubjects.csv"

So, the contents of uploadcsv.php goes here...
I'll explain PHP code wherever necessary, in PHP comments.

<?php
/*
$argv handles command line input
The first element of the array is the php script filename itself.
So we'll remove it.
*/
array_shift ($argv);

/*
We're going to upload several tables in different files.
To upload three files we need three FTP connections.
Archiving makes the three one. And finally we need one FTP connection.
So it reduces the time spent for the work to be done.
For archiving I used the Archive Tar library
which is available at http://pear.php.net/package/Archive_Tar/
*/
require_once ("Tar.php");
$tar = "exportcsv.tar";
$tarfile = new Archive_Tar ($tar);
$tarfile->create ($argv);
unset ($tarfile);

/*
Now we can delete the temporary CSV files
*/
foreach ($argv as $file)
{
 unlink ($file);
}

/*
Archiving isn't just enough when file size becomes quite large to upload.
We have several compression methods available
that can drastically reduce the file size.
PHP provides methods to compress data into bzip2 format,
where very high compression ratios are achievable.

When you compress a set of files into one in your computer,
it automatically performs the two steps of archiving and
compressing as a single step.

In my work, archive was 19.xx MB and after compression
it took just 3.xx MB
*/
$finale = $tar . ".bz2";
$bz2 = fopen ($finale, "w");
$bz2data =

unlink ($tar);

$upload_md5 = md5_file ($finale);
/*
As we are uploading this file,
we need to verify it's integrity at the
remote end before processing. I used MD5 to
verify the uploaded file's integrity.
Please read http://en.wikipedia.org/wiki/MD5 for more information.
*/

/*
Our data is ready now.
Next is to upload it using FTP
*/
$remote_path = "/home/example/ftp/" . $finale;
/*this is the remote directory where we're going to upload the file.
For security reasons this should be outside of the website's document root (/home/user/public_html) */
$ftp_host = "example.com";
$ftp_user = "example";
$ftp_pass = "p4ssw0r!";

$conn = ftp_connect ($ftp_host,);
ftp_login ($conn, $ftp_user, $ftp_pass);
ftp_pasv ($conn, true);

if (!ftp_put ($conn, $remote_path, $finale, FTP_BINARY))
{
 die ("Upload failed!"); // Abort if upload failed.
}

ftp_close ($conn);

/*
After the upload has finished, we need to tell
the website that the uploaded file is ready to be
proceed.

We can do this with a HTTP GET but some part of the actual system inspired me to use SOAP.
For simplicity of this article I may use a HTTP request here.

*/

$final_result = file_get_contents ("http://www.example.com/importer.php?file=" . $finale . "&checksum=" . $upload_md5);
/* where www.example.com is the remote location where we keep the script to import data from CSV files */

if ($final_result == "Success!")
{
 echo "One way sync successful!";
}
else
{
 echo "Synchronization failed!\n";
 echo $final_result;
}

Alright. Finally, one more step ahead... data is ready to be imported to MySQL.
It's that importer.php that we called in the earlier script. We need to keep this file inside the document root of the website so it can be called over HTTP.
I'll put the code here, explaining each piece, in the same way as the above.

<?php

require_once ('Tar.php');

/*
MySQL Database configuration
*/
$db_server = 'localhost';
$db_user  = 'example';
$db_pass  = 'p4ssw0r!';
$db     = 'example_com';

/*
Directory path (on the remote server) where the uploaded file is kept
*/
$basedir = "/home/example/ftp/";

/*
Connect to the MySQL database
*/
$conn = mysql_connect ($db_server, $db_user, $db_pass);
if (!$conn) { die ("MQSQL database connection failed! Can't continue."); }
mysql_select_db ($db, $conn);


/*
Validate the upl;oaded file against the MD5 checksum
*/
$filename = trim ($_GET['file']);
$checksum = trim ($_GET['checksum']);

$md5 = md5_file ($basedir . $filename);
if ($md5 != $checksum)
{
 die ("File checksum mismatch. Please try again!");
}


/*
Decompress the uploaded file and extract the archive.
Whenever a file becomes no longer necessary,
it is deleted using unlink ()
*/
$arch = $basedir . substr ($filename, 0, -4);
$bz2data = implode ("", file ($basedir . $filename));
$data = bzdecompress ($bz2data, true);
$fp = fopen ($arch, "w");
fwrite ($fp, $data);
fclose ($fp);
unlink ($basedir . $filename);

$tar = new Archive_Tar ($arch);
$tar->extract ($basedir);
unlink ($arch);


/*
Now we have CSV files back, in the server space.
Next task is to find them, and import to MySQL
using a LOAD DATA LOCAL query.

When a particular directory is scanned with scandir () for files,
it returns an array containing the current directory and one level
upper directory as the first two elements. We have to
skip these two before using the return value.
*/
$fl = scandir ($basedir);
array_shift ($fl);
array_shift ($fl);

/*
A simple loop is used to import each table.
Here each filename (without extension) is equvalant to the
table name in MySQL. That means, the table names are identicle
to the table names in the original Access database.
Otherwise we need to do a small workaround to fix any mismatch.
*/
foreach ($fl as $file)
{
 if ($file != $filename) {
  $src = realpath ($basedir . $file);

  /*
  Strip '.csv' from the filename to get the exact table name
  */
  $tblname = str_replace (".csv", "", $tblname);
  $tblname = strtolower ($tblname);

  /*
  Empty the table before importing
  to prevent duplicate records.
  */
  $q = "TRUNCATE TABLE $tblname";
  mysql_query ($q);
  /*
  This query handles importing CSV to MySQL directly.
  If this functionality was not there with MySQL
  then it would be a certain workaround to import the tables.
  */
  $q = "LOAD DATA LOCAL INFILE '$src' REPLACE INTO TABLE $tblname FIELDS TERMINATED BY ','
  OPTIONALLY ENCLOSED BY '\"' LINES TERMINATED BY '\r\n'";
  $ret = mysql_query ($q);
  unlink ($src);

  if ($ret != true)
  {
   echo "MySQL query failed!";
  }
 }
}

/*
Everything is complete.
Close the MySQL database connection
*/
mysql_close ($conn);

Finished! Now, additionally we can automate the whole task to make sure the one way synchronization happens time to time.


Making the whole task fully automated

This actually doesn't need anything to do with coding. We need to set up one macro on Access database, and a scheduled task on Windows.

Although I have prepared a clean user manual for our client, I do not wish to do it here in detail here as I am writing this note to technical people. The macro on Access database should go like this,

Action	Arguments	Comment
RunCode	ExportData ()	-
Quit	Prompt	-

Give the macro a meaningful name. Here I use Sync.

What we're going to do is, periodically open the database file with Microsoft Access, and then automatically execute the macro so it can trigger the function inside the VBA module. But, by default Microsoft Office blocks macros.

We need to prevent Microsoft Access from blocking the macro. Unless we can't automate the task. To do this, create a trusted location and place the database file there.

Finally, we need to set up a scheduled task on Windows, and the program/ command line should go like this,

msaccess.exe "C:\Database.accdb" /ro /nostartup /x Sync


This is my approach. Now, the leftover work is to apply security if necessary, and then sit back, relax, and watch it go! :-)

• This implementation is not secure if tables carry sensitive data. Someone can sniff the data in the middle and study the pattern how it works. For additional security we can use SFTP instead of FTP upload. To do this, we can use SSH2 functions for PHP.
• Also, when calling the 'importer' script we can use SSL encryption. Also it is possible to attach this functionality to the index.php file of the website.

• If the target MySQL tables have DATE fields, this will import the dates incorrectly as MySQL expects the date exactly in four digit year-two digit month- two digit date  (ex. "2010-12-25") format.
• I haven't tested how this would handle primary keys and relationships in the target database. In my case the data in MySQL database was for just displaying only. So it didn't have any keys.

• MySQL LOAD DATA INFILE Syntax
• Microsoft Office Access 2007 Support
• PHP Manual

This was my approach. If you have a different approach, or any comments, below you have space to write. Comments and expert advice are warmly welcome. :-)

Thanks for reading!

---

PS:
This wouldn't be a much workaround if there were timestamps in the source tables. But the business client was not willing to change his existing database structure. But, this is what I had and how I solved it. They ask and we got to shut up and do.
